Garage Door Breadboard Demo
How to put your first opener circuit together on a breadboard for initial testing.
Intro
The purpose of this session is to familiarize you with breadboards and get you prototyping quickly and easily.
Materials required.
For this session you will need
- a bundle of breadboarding wire,
- a breadboard,
- an ESP32 S3 dev board,
- a USB cable.
- Male-female header wires
- Transistor. NPN.
- Two LEDs, one red, one green.
- A small set of mixed resistors.
- A 5V 1A (min) power supply
- oscilloscope (preferred) or multimeter (minimum)
